With our Longspan shelving's modular design, and fast and easy assembly you can achieve the maximum possible storage capacity, regardless of the space you have available.

The Longspan Shelving system allows for the easy adjustment of storage heights and configurations as your requirements change; providing a system that moves and changes with you.

Longspan is equally suited for warehouse and office environments; easily configurable for a number of different applications. From low level hand-loaded shelving, to high-rise systems.

Incorporating varying frame and beam sizes, customising the system for your exact needs is really straightforward. Medium- and Longspan bays can be combined in the same rack, and a bolt-free, lock-in system ensures support beams remain in position. Longspan frames and beams are powder-coated anthracite and grey white.

Our Longspan shelving has been designed and tested to comply with the recommendations of the FEM Shelving Design Code 10.2.06.

Standard Dimensions

  • Depth 450 / 600 / 750 / 900/ 1000 / 1200 mm
  • Length 1200 / 1500 / 1800 / 2400 / 2700 (TBA)
  • Height 1500 / 2000 / 2500 / 3000

Four upright sections to give the optimum configuration for customer

  • 50/150
  • 50/175
  • 60/175
  • 60/200

Loading

  • Load per level Up to 800 kg
  • Load per bay Up to 4500 kg

Finish

  • Uprights - Galvanized
  • Beams – Painted RAL 9002 (other colours possible)

Accessories

  • Galvanized and Painted

Other dimensions can be manufactured according to customer and project requirements.
